CS-ARC-Q420/Q580 Chillers
- Small, portable and light weight design.
- Intelligent frequency conversion, low energy consumption.
- Temperature stability is ±0.1℃
- Flow alarm
- Over-high and over-low temperature alarm
- Alarm signal output
- High-definition LCD screen display
- RS485 communication (optional)
- AC220V (standard), AC110V/DC24V (optional)
| Item | Unit | CS-ARC-Q420A110/A111 | CS-ARC-Q580A110/A111 |
|---|---|---|---|
| Nominal Cooling Capacity (@25℃ ambient, 25℃ water) | W | 420 | 580 |
| Rated Voltage / Frequency | V/Hz | 220V / 50-60Hz (110V available) | |
| Rated Power | W | 280 / 290 | 360 / 380 |
| Pump Head | m | 13 / 20 | 20 / 25 |
| Max Flow | L/min | 23 / 24 | 24 / 25 |
| Refrigerant Type | - | R134a | |
| Water Tank Capacity | L | 1.8 | |
| Temperature Setting Range | ℃ | 10 ~ 35 | |
| Temperature Stability | ℃ | ±0.1 | |
| Working Temperature | ℃ | 0 ~ 45 | |
| Storage Temperature | ℃ | -10 ~ 60 | |
| Net Weight | kg | 11 | |
| Gross Weight | kg | 12 | |
| Circulating Fluid | - | Water / Glycol Water | |
| Inlet / Outlet | - | 10mm Pneumatic Joint | |
| Chiller Size (excluding protrusions) | mm | 345 × 248 × 215 | |
| Package Size | mm | 410 × 310 × 273 | |

Advantages
Our chillers utilize eco-friendly refrigerants, balancing high performance with sustainability. Featuring high-precision temperature control capabilities (±0.1°C), they meet the exacting requirements of precision equipment. Through optimized system design, they achieve lower energy consumption and a higher Coefficient of Performance (COP). Furthermore, their efficient and stable cooling capacity ensures reliable performance even during prolonged periods of continuous operation.
